APL-DP-EC

APL-DP-EC is a Class III direct drive backward curved airfoil wheel plenum fan with an Infinitum Aircore EC motor. The APL-DP-EC is recognized for space and energy savings. The APL-DP-EC is an unhoused fan with a welded painted steel frame construction and is commonly used in air handling unit applications such as Data Centers.

Features

• Welded painted steel construction
• Class III capability
• Customizable - call factory for details
• Airfoil wheel backward curved
• Integrated VFD

Benefits

• Smaller, lighter, quieter, more efficient
• Close-coupled VFD saves installation costs
• 66% less copper than conventional induction and EC motors
• PCB-stator technology is 9x more reliable than copper-wound iron core stators
• Modular design requires less labor to install, is easier to maintain, and offer redundancy and higher reliability
• Multiple control options: MODBUS, 0-10 VDC, 4-20mA, speed taps
• Built-in sensors with optional IoT connectivity makes predictive and prescriptive maintenance easy

Using innovative PC stator technology, Infinitum Aircore EC motors offer class-leading efficiency in a smaller package. The Aircore EC provides the market’s most comprehensive range of power and frame sizes along with loT capabilities, bringing smart motor technology to a wide range of HVAC and industrial applications.

Infinitum Aircore EC Motor

Optimized efficiency
Aircore EC motors easily mount directly to fan applications and increase efficiency by 10-15% over conventional systems. Infinitum motors run at variable speeds, saving energy at offpeak times and maintaining efficiency. Save on your energy bill and improve your PUE (Power Usage Effectiveness).

Serviceable solutions
Our solutions require less labor to install, are easier to maintain, offer redundancy and higher reliability. The integrated VFD paired with optional IoT connectivity makes predictive and prescriptive maintenance easy. In the event a component ever needs replacing, the modular design facilitates replacing just that part rather than the entire motor or fan.

Sustainable design
Our lightweight, PCB stator uses 66% less copper than conventional iron-core stators. Aircore EC motors are 50% smaller and lighter, requiring less material for the housing — further reducing transportation emissions by 30%. We remanufacture our motors to take advantage of components that can be kept in service and out of the landfill.

• Highest wire-to-air efficiency in the industry and highefficiency across a wide range of load conditions to improve a data center’s power usage effectiveness (PUE).
• Operational cost savings through higher energy efficiency of the fan wheel with significant savings on electrical infrastructure build-out, and reduced maintenance costs.
• Modular design for serviceability, limits potential downtimes — leads to longer life of the cooling system and compelling TCO over its lifetime.
• Sustainability spanning the entire lifecycle of the motor with reduced raw materials and end-of-life reuse/remanufacturing practices — all enhancing the Carbon Usage Effectiveness (CUE).
• Infinitum motors feature PCB stators to create a magnetic field, in contrast to traditional copper wound iron core stators, which are more durable, reliable, and last 9x longer on average.
• Short lead times, quick delivery, and supply chain versatility (with the top fan providers in the industry) to meet the demands of today’s industrial applications.
